Omschrijving
3GBA132250-BSD DRAAISTROOMMOTOR
Product TEFC, 3-phase, squirrel cage induction motor
Product code 3GBA 132 250-BSD
Type/Frame M2BAX 132SME 4
Mounting IM3001, B5(flange)
Rated output PN 7,5 kW
Service factor 1
Type of duty S1(IEC) 100%
Rated voltage UN 400 VY
Rated frequency fN 50 Hz
Rated speed nN 1465 r/min
Rated current IN 15,4 A
No-load current 7,5 A
Starting current Is/IN 7,4
Nominal torque TN 49 Nm
Locked rotor torque TS/TN 2,5
Maximum torque Tmax/TN 4
Minimum torque Tmin/TN 2,1
Speed at minimum torque 300 r/min
